UV germicidal device
Описание
Ultraviolet sterilizers are designed for water disinfection by ultraviolet radiation. Ultraviolet irradiation is an economical and the most environmentally friendly way of water disinfection. It is used to remove organic impurities from the composition of water. The method is absolutely safe for human health. Often UV treatment is combined with other filters and is one of the stages of multi-level purification. This type of equipment is suitable both for treated wastewater and for disinfection of drinking water.
| Модель УФ | Диаметр корпуса, мм | Длина корпуса, мм | Производительность, м3/час | ПМощность (кол-во) ламп и баластов, вт х шт | Размеры подключения (вход и выход), мм | Стоимость, сом |
|---|---|---|---|---|---|---|
| UVL 80 | 89 | 900 | 6 | 80 | DN25/1" | 1 000 000 |
| UVL 160 | 108 | 900 | 15 | 80х2 | Ф25 /2" | 1 000 000 |
| UVL 240 | 133 | 900 | 22 | 80х3 | Ф25 /2" | 1 000 000 |
| UVL 480 | 219 | 900 | 45 | 80х6 | DN65 Fl | 1 000 000 |
| UVL 560 | 219 | 900 | 52 | 80х7 | DN100 Fl | 1 000 000 |
| UVL 800 | 220 | 900 | 75 | 80х10 | DN200 Fl | 1 000 000 |
| UVL 160 | 108 | 900 | 15 | 80х2 | Ф25 /2" | 1 000 000 |
| UVL 80 | 89 | 900 | 6 | 80 | DN25/1" | 1 000 000 |
| UVL 160 | 108 | 900 | 15 | 80х2 | Ф25 /2" | 1 000 000 |
| UVL 320 | 133 | 900 | 35 | 80х4 | DN65 Fl | 1 000 000 |
| UVL 480 | 219 | 900 | 45 | 80х6 | DN80 Fl | 1 000 000 |
| UVL 560 | 219 | 900 | 52 | 80х7 | DN100 Fl | 1 000 000 |
| UVL 800 | 220 | 900 | 75 | 80х10 | DN200 Fl | 1 000 000 |
| UVL 560 | 219 | 900 | 52 | 80х7 | DN100 Fl | 1 000 000 |
| UVL 800 | 220 | 900 | 75 | 80х10 | DN200 Fl | 1 000 000 |
| UVL 560 | 219 | 900 | 52 | 80х7 | DN100 Fl | 1 000 000 |
